Visiport® VP220.C2

The new Visiport® VP220.C2 (digital drive) is identical with the model VP 220.C (analog drive) and differs only with its new digital motor controller. The new digital motor controller features the latest technology.  The new VP220.C2 includes all the winning features of the VP220.C including additional drainage features.
The drive is exclusively digital controlled and programmable, to optimize the function. The deviation of the motor speed (RPM) is less than ± 0,5%.
Power 24V ± 1V.
The opto-electric switch is no longer in the VP220.C2 as the torches in the world market are almost been replaced 100% by LED lamps. The LED light frequency is not registered on switch.



Modification of Visiport® VP220.C2
FDX     Basic model, direct screw coupling on polycarbonate panes (Mounting Plate not supplied)
FMX    Basic model, with VHB adhesive tape on basic unit (Mounting Plate not supplied)
FVX     Basic model, VHB adhesive tape on extra mounting plate for easy replacement
HM      same as FMX, but with separate terminal box
HV      same as FVX, but with separate terminal box

Features

  • All new digital motor controller
  • Extra drainage features to accomplish with high coolant volume applications
  • Installs on both glass laminate and polycarbonate machine tool windows, as well as integrated system
  • Light weight aircraft aluminum construction.
  • Integrated surface-mount electronics with reverse polarity protection.
  • Brushless DC motor, 24 VDC, 5 Amp minimum supply requirement.
  • Steady state current draw 250 mA (with no coolant load).
  • Long life, instrument-rated bearing set.
  • Balanced, rotating disc window, with chemically strengthened glass.
  • Optional DLC* coating for 10X plus resistance to glass wear.
  • Mounting plate for easy installation and low life-cycle cost.
  • Sealed connection cavity with exit ports left, right, and bottom.
  • Steel wire Flex conduit or Polyurethane tubing for harness routing (EO/EO2 optional).
  • Terminal box with mechanical on/off/reset toggle switch.
  • Balanced, rotating disc window, with chemically strengthened glass.
  • One year limited warranty.
